M8 JACK to CUTTING END M8 JACK to CUTTING END
M8 JACK to CUTTING END M8 JACK to CUTTING END

M8 JACK to CUTTING END

  • THE PRODUCT HAS BEEN TESTED BY CABLE TESTER FOR CONTINUITY AND SHORT CIRCUIT.
  • THE PRODUCT PASSED CE EN55032/55035 EMC TEST.
  • THE PRODUCT PASSED IP67 TEST. ( M8 PLUG )
  • THE PRODUCT IS UL-CERTIFIED.



  • The outer shell of the M8 connector has a "Wrench-Flat" design for fastening torque. Recommend 0.4 NM ( 3.54 lb-ft. )

  • CABLE：
    • OPTION 1. - UL20549 22AWG x 4C UNSHIELDED、FLEXIBLE CABLE，TPU JACKET
    • OPTION 2. - UL20549 24AWG x 3C SHIELDED、FLEXIBLE CABLE，TPU JACKET
    • OPTION 3. - UL20549 24AWG x 4C SHIELDED、FLEXIBLE CABLE，TPU JACKET
  • JACKET COLOR： MATTE BLACK
  • OVERALL LENGTH：0.5 - 15 M
  • CONNECTOR：
    • OPTION 1. - M8 3P A-Coded JACK
    • OPTION 2. - M8 4P A-Coded JACK
  • CONTACT MATERIAL & FINISHING： BRASS / GOLD PLATING ( 10μ" )
  • CONNECTOR FORM TYPE： PVC OVER-MOLD
