M12 PLUG TO RJ45

  •
  • THE PRODUCT HAS BEEN TESTED BY CABLE TESTER FOR CONTINUITY AND SHORT CIRCUIT.
  • THE PRODUCT PASSED CE EN55032/55035 EMS TEST.
  • THE PRODUCT PASSED IP67 TEST. ( M12 PLUG )
  • THE PRODUCT IS UL-CERTIFIED. ( for 22AWG cable only )



  • The outer shell of the M12 connector has a "Wrench-Flat" design for fastening torque. Recommend 0.6 NM ( 5.31 lb-ft. )

  • CABLE：
    • OPTION 1. - Cat.5e SF/UTP 4C x 22AWG STRANDED SHIELDED CABLE，TPU JACKET
    • OPTION 2. - Cat.5e SF/UTP 4C x 26AWG STRANDED SHIELDED CABLE，TPU JACKET
  • JACKET COLOR： GREEN
  • OVERALL LENGTH：0.5 - 15 M
  • CONNECTOR 1. - M12 4P D-Coded PLUG
  • CONNECTOR 2. - SHIELDED CONNECTOR(RJ45)
  • CONTACT MATERIAL & FINISHING：BRASS / GOLD PLATING ( M12 10μ"，RJ45 50μ" )
  • PINOUT TYPE： ACCORDING TO IEC 61918 APPENDIX H
  • CONNECTOR FORM TYPE： M12 PLUG SIDE - PVC OVER-MOLD
  • RJ45 BOOT MATERIAL： PVC
