M8 PLUG to M8 PLUG
- THE PRODUCT HAS BEEN TESTED BY CABLE TESTER FOR CONTINUITY AND SHORT CIRCUIT.
- THE PRODUCT PASSED CE EN55032/55035 EMC TEST.
- THE PRODUCT PASSED IP67 TEST.
- THE PRODUCT IS UL-CERTIFIED. ( for 22AWG cable only )
- The outer shell of the M8 connector has a "Wrench-Flat" design for fastening torque. Recommend 0.4 NM ( 3.54 lb-ft. )
- CABLE：
- OPTION 1. - Cat.5e SF/UTP 4C x 22AWG STRANDED SHIELDED CABLE，TPU JACKET
- OPTION 2. - Cat.5e SF/UTP 4C x 26AWG STRANDED SHIELDED CABLE，TPU JACKET ( This option is currently unavailable.)
- JACKET COLOR： GREEN
- OVERALL LENGTH：0.5 - 15 M
- CONNECTOR：M8 4P A-Coded PLUG
- CONTACT MATERIAL & FINISHING： BRASS / GOLD PLATING ( 10μ" )
- PINOUT TYPE： ACCORDING TO IEC 61918 APPENDIX H
- CONNECTOR FORM TYPE： PVC OVER-MOLD
