M12 PLUG to M12 PLUG M12 PLUG to M12 PLUG
M12 PLUG to M12 PLUG M12 PLUG to M12 PLUG

M12 PLUG to M12 PLUG

  •
  • THE PRODUCT HAS BEEN TESTED BY FLUKE DSX2-8000 TIA-568 PATCH CORD. (OPTIONAL)
  • THE PRODUCT PASSED CE EN55032/55035 EMC TEST.
  • THE PRODUCT PASSED IP67 TEST.
  • THE PRODUCT IS UL-CERTIFIED. ( for 22AWG cable only )



  • The outer shell of the M12 connector has a "Wrench-Flat" design for fastening torque. Recommend 0.6 NM ( 5.31 lb-ft. )

  • CABLE：
    • OPTION 1. - Cat.5e SF/UTP 4C x 22AWG STRANDED SHIELDED CABLE，TPU JACKET
    • OPTION 2. - Cat.5e SF/UTP 4C x 26AWG STRANDED SHIELDED CABLE，TPU JACKET
  • JACKET COLOR： GREEN
  • OVERALL LENGTH：0.5 - 15 M
  • CONNECTOR： M12 4P D-Coded PLUG
  • CONTACT MATERIAL & FINISHING： BRASS / GOLD PLATING ( 10μ" )
  • PINOUT TYPE： ACCORDING TO IEC 61918 APPENDIX H
  • CONNECTOR FORM TYPE： PVC OVER-MOLD
